供水標識樁的設置要求和距離標準

         Requirements and distance standards for setting water supply marker piles

　　一、基本設置要求

　　1、 Basic setup requirements

　　給水管標志樁是指為了明確給水管線路的走向、位置、型號等信息而設置在管道或地面上的標志物。在給水工程中，為了保證給水管網的管理和維護，需要按照規定的要求設置標志樁，以方便日后的管道維修和管理。

　　The water supply pipe marker post refers to a marker set up on the pipeline or ground to clarify the direction, position, model, and other information of the water supply pipe line. In water supply engineering, in order to ensure the management and maintenance of the water supply network, it is necessary to set up marker stakes according to the prescribed requirements to facilitate future pipeline maintenance and management.

　　二、距離標準

　　2、 Distance standard

　　1. 標志樁的設置距離應符合規定，在城市主干道和重要交叉路口或有中間橋梁、隧道、立交等交通設施的地方，標志樁的設置間距不得超過50米；

　　1. The distance for setting up marker stakes should comply with regulations. In urban main roads, important intersections, or places with intermediate bridges, tunnels, overpasses, and other transportation facilities, the distance between setting up marker stakes should not exceed 50 meters;

　　2. 在城市次干道或者主次干道間距超過300米的路段或無交通設施的路段，標志樁的設置間距不得超過100米；

　　2. In urban secondary roads, sections with a distance between main and secondary roads exceeding 300 meters, or sections without traffic facilities, the spacing between sign posts shall not exceed 100 meters;

　　3. 在鄉村和旅游區域，標志樁的設置間距不應超過200米。

　　3. In rural and tourist areas, the spacing between sign posts should not exceed 200 meters.

　　三、標志樁的高度和標識

　　3、 The height and identification of marker posts

　　1. 標志樁的高度不得低于0.8米，不得高于1.5米；

　　The height of the marker post shall not be less than 0.8 meters and shall not exceed 1.5 meters;

　　2. 在標識上，應注明管道名稱、類型、規格、埋深、敷設時間和施工單位等信息；

　　On the identification, information such as pipeline name, type, specification, burial depth, laying time, and construction unit should be indicated;

　　3. 標志樁的顏色按照有關標準進行規定：一類管道為藍色，二類管道為綠色，三類管道為黃色，四類管道為紅色。

　　3. The color of the marker posts shall be specified in accordance with relevant national standards: Class I pipelines shall be blue, Class II pipelines shall be green, Class III pipelines shall be yellow, and Class IV pipelines shall be red.

　　四、總結

　　4、 Summary

　　給水管標志樁的設置要求和距離標準是對于標志樁的設置的基本要求，也是對于日后管理和維護的重要保障。在給水工程中，標志樁的設置要符合規定，標識要清晰明確，以便于日后的管理和使用。

　　The setting requirements and distance standards for water supply pipe marker piles are the basic requirements for the setting of marker piles, and also an important guarantee for future management and maintenance. In water supply engineering, the setting of marker piles should comply with regulations, and the markings should be clear and clear for future management and use.
